Flat Panel TV(LCD)

H USB G?LAN F?Audio Signal Processing/Audio Amplifier E?Analog Circuit D?Tuner C?Digital Circuit B?LCD Driver A?Power Supply Circuit

A Power Supply Circuit

Surface Mounting Type Leaded Type
Resistors RK73GRK73HRK73B CF
High Voltage / Resistors HV73
High Power Rating / Resistors WK73RSL
MOS(X)SPR(X)CW
Current Sensing / Resistors SR73UR73(D)WK73SSLTLRHTLR
MOS(X)SPR(X)BPR
Discharge Path/ Resistors HV73
RCR
Inrush Current Resistant / Resistors CWBWRBGR
Circuit Protection / Fuses CCF
Choke Coil / Inductors LPC
Large Current Jumper / Jumpers TLRZ

B LCD Driver

Surface Mounting Type Leaded Type
Resistors RK73GRK73HRK73B
Surge Resistant / Resistors SG73SSG73PSG73SG73GWG73
Circuit Protection / Fuses CCF,CCPTF16AT
Temperature Compensation / Thermistors NT73
Temperature Compensation / Linear Resistors LT73LP73

C Digital Circuit

Surface Mounting Type Leaded Type
Resistors RK73GRK73HRK73B
Circuit Protection / Fuses CCPTF16SN
Check Terminal / Checker Chips RCTRCU

D Tuner

Surface Mounting Type Leaded Type
Resistors RK73GRK73HRK73B
Tuning / Inductors KQKQC

E Analog Circuit

Surface Mounting Type Leaded Type
Resistors RK73GRK73HRK73B
Circuit Protection / Fuses CCF, CCPTF16AT
ESD Protection / Varistors NV73
Temperature Compensation / Thermistors NT73
Temperature Compensation / Linear Resistors LT73LP73
Choke Coil / Inductors LPC
Check Terminal / Checker Chips RCTRCU

F Audio Signal Processing/Audio Amplifier

Surface Mounting Type Leaded Type
Resistors RK73GRK73HRK73B
Choke Coil / Inductors LPC

G LAN

Surface Mounting Type Leaded Type
Resistors RK73GRK73HRK73B
Tuning / Inductors KQKQC

H USB Interface

Surface Mounting Type Leaded Type
Resistors RK73GRK73HRK73B
ESD Protection / Varistors NV73
