metal plate current sense resistor
	Features Ultra-low TCR (+75ppm/°C) available Metal alloy: superior corrosion and heat resistance Applications include current sensing, voltage division and pulse applications Ultra low resistance (1mO - 20mO) Products with lead-free terminations meet EU RoHS and China RoHS requirements AEC-Q200 Qualified: 0402 (1E), 0603 (1J), 0805 (2A), 1206 (2B), 1210 (2E), 2010 (2H/W2H), 2512 (3A/W3A)
