RD412A/2D Fixed Carbon Film MELF Resistors
EOL - End of Life
Last time to buy: 2/28/2023 Recommended Replacement SG73_2A Series, RD412ES, SG73_2B Series
Features
- Suitable for reflow and wave soldering
- Metal plate terminals
- Meets or exceeds IEC 60115-8, EIAJ RC-2131A
- Products with lead-free terminations meet EU RoHS and China RoHS requirements
Last Updated: 7/18/2022
Order Samples
Downloads
Catalog Pages
Full Line Catalog
Selection Guide3D Models
