SG73-RT Pulse/Surge

Features

• Excellent anti-sulfuration characteristic due to using high sulfuration-proof inner top electrode material/pulse
• Superior to RK73 series chip resistors in pulse withstanding voltage
• Suitable for both reflow and flow solderings
• Products with lead-free terminations meet EU RoHS requirements. EU RoHS regulation is not intended for Pb-glass contained in electrode, resistor element and glass.
• AEC-Q200 Tested
