RK73B-RT 2%, 5% Tolerance Thick Film Chip

Features

• Excellent anti-sulfuration characteristic due to using high sulfuration-proof inner top electrode material
• Excellent heat resistance and weather resistance are ensured by the use of metal glaze thick film
• High stability and high reliability with the triple-layer structure of electrode
• Suitable for both flow and reflow
• Products with lead-free terminations meet EU RoHS requirements. EU RoHS regulation is not intended for Pb-glass contained in electrode, resistor element and glass.
• AEC-Q200 Tested: 0201 (1H), 0402 (1E), 0603 (1J), 0805 (2A), 1206 (2B), 1210 (2E), 2010 (W2H), 2512 (W3A)
