SLR1 Thick Film

Features

• Thick film resistor protected by liquid crystal polymer resin
• Excellent heat cycle characteristics
• Encapsulated with flame retardant resin molding. (UL94 V-0)
• High operating temperature range up to 180°C
• Products meet EU RoHS requirements. EU RoHS regulation is not intended for Pb-glass contained in electrode, resistor element and glass.
• AEC-Q200 Tested
